It does not annoy me anymore!

Originally this part was programmed for and machined in 6061 aluminum, but when production run came, material was changed to HRS and then to SPS (4140).

Luckily reprogramming using HSMAdvisor hook for MasterCAM is a bliss.

Mere 5 minutes and all speeds, feeds, depths of cut, etc. were changed to safe and productive values.

New Material

Quite often i see people asking which text editors others use to work with their G-Code.

Some even suggest paid ones.

I am using a free general-purpose advanced text editor called Notepad++.
In fact i am using the same editor to create code for my apps too.

It is so flexible, it can recognize the language you are working with and turn on the language-specific highlighting for even the G-Code.

I have created my own Language profile for it. It is attached to this article, so everyone can download it.

Below is how you can apply this language profile to turn on g-code highlighting:

G-CODE_N Language

I just have to tell.

I know, I know I should not. But I am working on a very cool feature right now and I am extremely happy and proud with how well it comes together.

Okay. I can tell you that it has a word "Cloud" in it and that I have VERY high hopes for it.....Once fully implemented it will unite all of our Speeds and Feeds products in a huge way.

Keep tuned in. Closed testing is about to start very soon.

If you would like to participate in something groundbreaking and new, shoot me an email!

Only license holders can apply, though. I don't want it to leak too early.

Being a CNC Machinist/Programmer is sometimes more than simply creating a program and machining the actual part, often times it is about creating efficient and accurate fixturing.

In this little project:

I had to machine rectangular cut-outs and drill holes through an already-turned steel ring. Then I had to part each ring to 4 equal pieces.

There were about 100 such rings that worked out to 400 pieces in total.

After drilling holes on an indexer I had to machine a fixture to hold my part through 2 remaining set-ups.

First half of the fixture consists of the expanding mandrel:

The work-piece would be mounted on it like so. A hole on the side is used to properly position it:

Being a professional CNC Machinist myself with a good manual background I often find myself watching various machining videos and blogs.

Unlike others I do not often share somebody-else's work, I could just not walk past this one and not tell everybody how great I think this is....

This story was posted on "Russian reddit" and here is the direct translation of the author's post:

Lets begin with tyres. Vladimir (guy's name) decided to create the mould to make the rubber tyres himself. Here it is:

Here are the tyres he made with it. Beautiful aren't they?

He also made little differentials. Housings, gears. Everything made himself:

Being as vast and as complex as it is HSMAdvisor Tool Database may seem overwhelming for many users despite all the benefits of using it.

To address this issue I have just added a new category to our HSMAdvisor on-line Help resource called Tool Database & Tool Inventory

Here is a the opening article of that category:

In all there are 5 articles in there already describing many of its functions in detail.
Please check them out if you are not sure what the Tool Database does and how to use it.

And as always: when in doubt - ASK :)

We have just released a pretty important HSMAdvisor v1.217 update!

I strongly encourage everybody to go ahead and install it as it contains some big improvements.

What is new and improved in this update:

• New Tool Database Status Indicator:
  Status Bar Indicator showing whether the Database file is being written, up to date or if write has failed
• A Warning now shows up when HSMAdvisor is closed with DB changes not saved.
• Now you can not close HSMAdvisor until Database file has been written to the disk
• A local backup copy of Shared database is now created on each computer for cases when connection is unavailable.
• Fixed the problem when new Tools and Cuts were not added to the shared database
• Fixed some (./,) locale-related problems.
• Fixed the problem of some settings not being saved.

I would like to explain one new feature here - The Tool Data Base Status indicator:

On the status bar of HSMAdvisor screen you can now see The Tool Data Base Status indicator (later DB Status) icon.

HSMAdvisor the Hook for MasterCAM x9 has had massive changes since the last update

• Completely redone Operation Import/Export functionality
• Added "Insert Operation" command (Add it to MasterCam toolbar through Customize->Toolbars->HSMADVISOR->select item,select toolbar-> Add..)
• Reworked MC Toolbar Icons
• Better tool Recognition
• Added support for ALL milling (2d, 3d, HST) operations.
• Fixed a huge number of problems including those with coolant, tool numbers and some unsupported operations.

HSMAdvisor hook for MasterCAM currently supports only MC x9.

Due to large amount of work I have done on x9 hook I decided to not port it to support x8. I simply have no time resources to do so. I only have one life you know!

Later versions of MasterCAM will, however, be fully supported.

Every month we are getting a good amount of feedback and suggestions.

Everything is getting prioritized and eventually implemented. Urgent stuff is getting done fast. And other "nice to haves" are getting pushed down according to their usefulness / difficulty (yes, everyone secretly wishes my program could also edit and create HSM g-code :)).

It is amazing, but almost half of HSMAdvisor's features were originally suggested by our loyal users!

The latest update HSMAdvisor 1.213 addresses some of the feedback I have received last couple of months.

So the New features are:

1. Smart Depth and Width of Cut (DOC/WOC) suggestion (user suggested)
2. Compressing of Shared Tool DataBases
3. Display of Stock status on Tool DataBase tables (user suggested)
4. Various little improvements like new Heli-Coil reference, better DOC/WOC calculation better multitasking, etc. (mostly based on user feedback)

Let's go over the most important ones here:

I would like to thank each and every person who has helped us out on our many projects this year.

I wish all of you a Merry Christmas and a Happy New Year.

Thus I am kicking off the last sale of this year. It will run until January the 4th.

You can save 15% on all purchases over $90!

Cheers.

See you next year!

PS. I have just uploaded an update to address the latest feedback. Thank You and Enjoy.
